Macquarie Semiconductor and Technology on behalf of Inspire Technologies, Inc.

Estek Automation SDN BHD WIS-800D

Asset ID: 210634

Print spec sheet

Estek Automation SDN BHD

WIS-800D

Broadband Patterned Wafer Defect Inspection

Metrology Equipment

Equipment details:

Date of Manufacture: 1988

Currently Configured for: 200mm

Current Equipment Status: Available

Location of Equipment: Caldwell, United States

Available date: Currently Available

Wafer Inspection System


The Estek WIS 8000/800 is designed to

analyze substrates, films, and oxides.


FEATURES:

2 to 8 inch setup

Dark and light (dual) channel system

2 Cassette system


SPECIFICATIONS:

Detection 0.22um on silicon at 95% capture rate

Verified by NIST Standards

2 to 8 inch capable with proper setup

Current configuration is 4 to 8 inch

Dark and light channel system

Dark channel is used for detecting particles and any light scattering defects

Light channel is useful for detecting non-light scattering defects such as

mounds, dimples and non uniformity

Detects specular flaws, including large particles, mounds,

dimples, saw marks, grooves, fractures, slip, epi-spikes,

small particles on large grained surfaces, particles buried in/under a film

Remanufactured System to factory production specifications

NIST Calibration

Automatic cassette-to-cassette robotic wafer transport system

Non-contaminating robotic wafer handling system with sorting capability

Wis-8000 model/ includes two random access stages

Wafers per hour, 120

Configured to run Fluoroware PA-72 Series Cassette

Data printer

Color Monitor to display wafers
